Description
- 1. Dual colored PC, single piece, simple and elegant;
- 2. All plastic structure, no electric shock hazard;
- 3. Optical grade full arc PC cover, recessed light source design, wide lighting angle;
- 4. HIghly reflective material, gentle light and anti glare;
- 5. Wide voltage intelligent constant current, no flicker;
- 6. High quality LED lamp beads, high efficency, high CRI;
- 7. Seamless connection, easy to install, not recommanded to exceed 130W for multi connections.
Product Specifications
| Model | OPL-DG2822-4W | OPL-DG2822-8W | OPL-DG2822-12W | OPL-DG2822-14W | OPL-DG2822-16W |
|---|---|---|---|---|---|
| Input Voltage | AC176-265 | AC176-265 | AC176-265 | AC176-265 | AC176-265 |
| Power Rating | 4W | 8W | 12W | 14W | 16W |
| Luminous Flux (lm) | 360 | 720 | 1080 | 1260 | 1440 |
| CRI (Ra) | >80 | >80 | >80 | >80 | >80 |
| CCT (K) | 3000K/4000K/6500K | 3000K/4000K/6500K | 3000K/4000K/6500K | 3000K/4000K/6500K | 3000K/4000K/6500K |
| Power Factor | >0.9 | >0.9 | >0.9 | >0.9 | >0.9 |
| Materials | Double colored PC unibody | Double colored PC unibody | Double colored PC unibody | Double colored PC unibody | Double colored PC unibody |
| Product Dimensions L*W*H (mm) | 313*22*30 | 573*22*30 | 873*22*30 | 1023*22*30 | 1173*22*30 |
| Beam angle (°) | >160° | >160° | >160° | >160° | >160° |
| Single box size (mm) | 375*37*27 | 635*37*27 | 935*37*27 | 1085*37*27 | 1235*37*27 |
Light Distribution Ｃｕｒｖｅ
